Inside Helm - How Charts, Releases, and State Work in Kubernetes

What’s Inside a Helm Chart#

A Helm chart is a package that describes how your app should be deployed to Kubernetes. It’s structured, predictable, and — if you do it right — beautifully reusable.

1
my-chart/
2
  Chart.yaml              # metadata (name, version, dependencies, etc.)
3
  values.yaml             # default configuration values
4
  templates/              # Go templates for Kubernetes manifests
5
    _helpers.tpl          # reusable named templates and functions
6
  charts/                 # subcharts (dependencies)
7
  files/                  # arbitrary files used in templates
8
  crds/                   # CustomResourceDefinitions (installed first)
9
  .helmignore             # like .gitignore for packaging

Think of it as your app blueprint — flexible through values.yaml and easily overridden at deploy time.

Pro tip: CRDs in the crds/ directory are:

• installed first,
• not templated,
• and never upgraded or deleted — this protects existing Custom Resources and data.

What Actually Happens When You Run helm install#

Let’s break it down. When you run helm install, Helm doesn’t just “apply some YAML.” It follows a clear sequence:

• Loads the chart (local or remote).
• Merges values from multiple sources:
  • base values.yaml;
  • any additional files: -f base.yaml -f prod.yaml (left-to-right; later overrides earlier);
  • inline flags: --set, --set-string, --set-file, --set-json (these always take precedence).
• Renders Go templates into complete Kubernetes manifests.
• Applies them to the cluster.

On a clean install, Helm creates the resources.

If resources already exist and contain the correct Helm annotations (meta.helm.sh/*, app.kubernetes.io/managed-by=Helm), Helm will adopt them. Otherwise, you’ll see:

1
Error: invalid ownership metadata

During upgrades or rollbacks, Helm performs a three-way strategic merge — comparing the previous manifest, the new manifest, and the current cluster state — handled client-side through client-go.

Where Helm Stores Release State#

Every Helm release is stored inside your cluster. No external DBs, no magic.

By default, Helm saves release info in a Kubernetes Secret, though you can switch to a ConfigMap or SQL driver (PostgreSQL).

Default object structure:

1
kind: Secret
2
type: helm.sh/release.v1
3
metadata:
4
  name: sh.helm.release.v1.<release>.v<revision>
5
  namespace: <release-namespace>

The .data.release field contains a base64-encoded, gzip-compressed blob with:

• the chart archive,
• rendered manifests,
• merged values,
• hooks,
• and release metadata (revision, timestamps, status).

Because Secret data is base64-encoded by Kubernetes — and the release payload also includes encoded sections — the result is effectively nested encoding.

Heads up: etcd enforces a ~1 MiB limit for Secret data. If you hit:

1
Too long: must have at most 1048576 characters

switch to SQL storage:

1
export HELM_DRIVER=sql
2
export HELM_DRIVER_SQL_CONNECTION_STRING=postgresql://user:pass@host/db

Labels and Annotations#

Helm labels everything it manages to track ownership precisely.

Added automatically:

1
app.kubernetes.io/managed-by=Helm
2
meta.helm.sh/release-name=<release-name>
3
meta.helm.sh/release-namespace=<namespace>

Best-practice labels (usually added by chart templates):

1
app.kubernetes.io/instance=<release-name>
2
helm.sh/chart=<chart-name>-<version>

If these don’t match during an upgrade, Helm will refuse ownership — hence the classic invalid ownership metadata error.

What Is a Helm Release?#

A release is one installed instance of a chart with a specific set of values (in a namespace).

Each change — install, upgrade, rollback — becomes a new revision stored right in your cluster. No external database. No API extension. Just Kubernetes objects doing their job.

The Three-Way Merge Explained#

When you upgrade, Helm compares:

• the previous rendered manifest,
• the new manifest (after your changes),
• the current live resources.

Then it calculates a three-way strategic merge patch and applies only what changed — reducing disruption and preserving manual tweaks where possible.

NOTE

This logic runs client-side, not via Server-Side Apply. For CRDs or unstructured resources, Kubernetes uses JSON merge-patch, which can behave slightly differently.

Namespaces: Release vs Target#

Helm separates namespaces into two categories:

• Release namespace — where Helm stores its Secret or ConfigMap.
• Target namespaces — where chart resources are deployed (can be multiple).
• --create-namespace only creates the release namespace (the one you pass with --namespace).

If your chart deploys across namespaces, create them manually or template them inside your chart.

Tip: Avoid hardcoding metadata.namespace unless you really need to — otherwise helm template | kubectl apply might push resources to default.

Storage Drivers#

Helm supports multiple backends for storing release state:

1
export HELM_DRIVER=secret      # default (encoded, secure)
2
export HELM_DRIVER=configmap   # readable, not encrypted
3
export HELM_DRIVER=sql         # PostgreSQL – best for large releases
4
export HELM_DRIVER=memory      # ephemeral, for tests only

Managing Release History#

Helm keeps all revisions unless you limit it. You can cap history like this:

1
helm upgrade --history-max 10 ...
2
export HELM_MAX_HISTORY=10

Explore release history anytime:

1
helm history <release>
2
helm get values <release>
3
helm get manifest <release>

TL;DR#

Helm isn’t magic — it’s clean engineering. Behind every helm install, it:

• loads, merges, and renders templates,
• stores state inside your cluster,
• tags resources for ownership tracking,
• applies three-way strategic merges on upgrade,
• manages revisions — all with zero external dependencies.

Once you understand how Helm really works, it stops feeling mysterious and starts feeling like your favorite DevOps assistant.

Quick Debug Tip#

1
helm ls -A
2
kubectl get secrets -A -l "owner=helm" -l "status=deployed"

Perfect for quick audits or just checking what Helm has been managing lately.
